Key Specifications:

• Boat Size Compatibility: 70–85 feet | Up to 75 tons
• Power Source: AC power required
• Unit Weight: 3,155 lbs (1,431 kg)
• Dimensions: 51″ L x 56″ W x 40″ H
• Warranty: 2 years or 2,000 hours (whichever comes first)
  Extended warranty available

Performance:

• Maximum Rated Speed: 5,000 RPM
• Angular Momentum (Max RPM): 26,000 N·m·s
• Anti-Rolling Torque (Max RPM): 68,703 N·m
• Spool-Up Time to Max RPM: 75 minutes
• Time to Stabilization (4,250 RPM): 55 minutes

Power Consumption:

• Operating Power: 1,375 – 3,000 Watts (depending on sea conditions)
• Spool-Up Power: Up to 3,000 Watts
